MNS-PC – Computer-Based Dot Peen Marking Machine

$8,789.00 Incl. GST

MNS-PC dot peen marker with PC control, 120x100mm area, barcode marking, Ethernet/WiFi, and support for both pneumatic and electric versions.

SKU: MNS-PC Category:

Description

PC-Controlled Precision with Deep, Permanent Marking

The MNS-PC is the rugged workhorse of the MarknStamp range—built for demanding marking environments. Designed for integration and long-duty cycles, it’s available in both pneumatic and electromagnetic versions to suit your marking depth and speed requirements.

This computer-based dot peen marking system connects via Ethernet or Wi-Fi, offering seamless PC operation and full control over marking settings, alpha-numeric content, and even 2D barcode generation like QR codes and Datamatrix.

It mounts securely to a heavy-duty stand and comes standard with 2-axis control (with options to upgrade to 3 or 4 axes). Whether you need deep marks, crisp barcodes, or high-speed continuous lines, the MNS-PC delivers reliable, industrial-grade results.

🔩 Key Technical Specifications:

  • Marking Area: 120mm x 100mm

  • Versions: Available in Pneumatic and Electromagnetic

  • Stylus Options: PH-16 (Continuous Marking) or LP-10 (Dotted Marking)

  • Technology: Dot Peen and Vibro Peen supported

  • Power Supply: 24VDC 5A via external adapter

  • Inputs: 5 for automatic design selection

  • Outputs: 2 (Marking complete, machine ready, error output)

  • Connectivity: Ethernet and Wi-Fi

  • Barcode Capability: Supports QR Code and DataMatrix

Whether you’re marking parts in an assembly line or integrating with robotic systems, the MNS-PC Dot Peen Marker is designed for high-accuracy, low-maintenance performance with deep, permanent results.
